Product Summary

4Mbit Asynchronous F-RAM Memory

Parametrics

4Mbit Ferroelectric Nonvolatile RAM
? Organized as 256Kx16
? Configurable as 512Kx8 Using /UB, /LB
? 1014 Read/Write Cycles
? NoDelay? Writes
? Page Mode Operation to 40MHz
? Advanced High-Reliability Ferroelectric Process
SRAM Compatible
? JEDEC 256Kx16 SRAM Pinout
? 55 ns Access Time, 110 ns Cycle Time
Advanced Features
? Software Programmable Block Write Protect
Superior to Battery-backed SRAM Modules
? No Battery Concerns
? Monolithic Reliability
? True Surface Mount Solution, No Rework Steps
? Superior for Moisture, Shock, and Vibration
Low Power Operation
? 2.7V – 3.6V Power Supply
? Low Current Mode (5μA) using ZZ pin
? Low Active Current (8 mA typ.)
Industry Standard Configuration
? Industrial Temperature -40° C to +85° C
? 44-pin “Green”/RoHS TSOP-II package

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FM22L16-55-TG
FM22L16-55-TG

Ramtron

F-RAM 4M (256Kx16) 55ns F-RAM

Data Sheet

0-1: $17.25
1-10: $15.49
10-50: $14.03
50-100: $12.70
FM22L16-55-TGTR
FM22L16-55-TGTR

Ramtron

F-RAM 4M (256Kx16) 55ns F-RAM

Data Sheet

0-1000: $10.33
