Product Summary
New and original
Parametrics
1Mbit Ferroelectric Nonvolatile RAM
? Organized as 128Kx8
? High Endurance 100 Trillion (1014) Read/Writes
? NoDelay? Writes
? Page Mode Operation to 33MHz
? Advanced High-Reliability Ferroelectric Process
Superior to Battery-backed SRAM Modules
? No battery concerns
? Monolithic reliability
? True surface mount solution, no rework steps
? Superior for moisture, shock, and vibration
SRAM Replacement
? JEDEC 128Kx8 SRAM pinout
? 60 ns Access Time, 90 ns Cycle Time
Low Power Operation
? 2.0V – 3.6V Power Supply
? Standby Current 90 ?A (typ)
? Active Current 7 mA (typ)
Industry Standard Configurations
? Industrial Temperature -40? C to +85? C
? 32-pin “Green”/RoHS Package
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 FM28V100-TG |
Ramtron |
F-RAM 1M (128Kx8) 2.2-3.6V F-RAM |
Data Sheet |
|
|
||||||||||||
|
FM28V100-TGTR |
Ramtron |
F-RAM 1M (128Kx8) 2.2-3.6V F-RAM |
Data Sheet |
|
|
||||||||||||
